24V DC 433,92MHz Shutter Controller via Rolling Code
GADC - Functional Motor Control Board 24V DC
Control Board
GADC - Functional Motor Control Board 24V DC
TECHNICAL FEATURES
| Model | GADC |
|---|---|
| Product Code | K034-01 |
| Working Volatage | 24V DC |
| Working Current | 50mA @12V |
| Working Frequency | 433,92MHz (External, Optional) |
| Contact Type | 24V DC |
| Contacting Time | 0,4 – 90sn |
| Max. Contact Power | 250V AC 10A |
| Weihgt | 260gr |
| Transmitter Count | 500 |
| Dimensions (Width x Length x Depth) | 96 x 157 x 47mm |
