Functional shutter controller is an AC motor drive card that can be controlled by control. It is used for the control of motor which used for garage doors, sliding doors and barrier systems.
QULP G - Functional Motor Control Board
Control Board
QULP G - Functional Motor Control Board
TECHNICAL FEATURES
| Model | qulp G |
|---|---|
| Product Code | K142-01 |
| Working Volatage | 220V 50Hz AC |
| Working Current | 30mA @220V |
| Working Frequency | 868,35MHz |
| Contact Type | 220V AC |
| Max. Contact Power | 250V 10A AC |
| Max. Contacting Time | 0,3 – 300sn |
| Auto-Learning | ü |
| Remote Control Capacity | 500 |
| Weihgt | 450gr |
| Dimensions (Width x Length x Depth) | 109,01 x 150,43 x 45,50 mm |
